Module Server
Intent Architect offers a self-hostable "Module Server" in the form of a Docker image. The Module Server Client CLI can be used to upload Modules and Application templates to it and then Intent Architect clients can be configured to use the server as a repository for your organization's custom Modules and Application Templates.
Dependencies
The Module Server uses Microsoft SQL Server for persistence, all editions of SQL Server 2019 and later should be compatible, including the free SQL Server Express edition.
A SQL Server schema migration script will need to be manually run on the SQL Server before the Module Server to be able to start up. The migration script is at the bottom of this article.
The Module Server is otherwise self-contained.
Docker image details
Name | Value |
---|---|
Registry | crintentarchitectprodzanorth.azurecr.io |
Repository | intent-architect/module-server |
User | anonymous |
Password | 1Ww/o4nfLPIKdComVBukyVGlmtWVgYm7MgfVPwwnfO+ACRAX3G9B |
Configurable environment variables
ConnectionStrings__DefaultConnection
Description: The Microsoft SQL Server connection string.
Default value: Server=host.docker.internal;Initial Catalog=Intent;MultipleActiveResultSets=True;Encrypt=False;User ID=module-server;Password=password;
ApiKeys
Description: A semi-colon (;
) separated list of strings of which any can be used as the value for the api-key
argument for the Module Server Client CLI.
Default value: (blank)
APPLICATIONINSIGHTS_CONNECTION_STRING
Description: Optional. An Azure Application Insights connection string. Leave unset or use the default value to have Azure Application Insights be disabled for the Module Server.
Default value: InstrumentationKey=00000000-0000-0000-0000-000000000000;
Running locally
Ensure Docker is installed.
Authenticate against the Intent Architect container registry:
docker login -u anonymous -p 1Ww/o4nfLPIKdComVBukyVGlmtWVgYm7MgfVPwwnfO+ACRAX3G9B crintentarchitectprodzanorth.azurecr.io
In the following command replace <sql-server-connection-string>
with a valid SQL Server connection string (e.g. Server=host.docker.internal;Initial Catalog=Intent;MultipleActiveResultSets=True;Encrypt=False;User ID=module-server;Password=password;
will connect to a SQL Server on the Docker host machine, to the Intent
database using the SQL username of module-server
and password password
) and then run it.
docker run --publish 33800:80 --name module-server -e "ConnectionStrings__DefaultConnection=<sql-server-connection-string>" crintentarchitectprodzanorth.azurecr.io/intent-architect/module-server:latest
You can confirm the module server is running by visiting http://localhost:33800/swagger/ in your web browser.
Deploying to Azure
Here is a simple guide on creating an Azure App Service which runs the Module Server Docker image.
Create the Azure resources
- Type app services in the search. Under Services, select App Services.
- In the App Services page, select + Create and then select the + Web App option.
- In the Basics tab, under Project details, ensure the correct subscription is selected and then select to Create new resource group. Type
intentArchitectModuleServerResourceGroup
for the name. - Under Instance details, type a globally unique name for your web app and select Docker Container. Select Linux for the Operating System. Select a Region you want to serve your app from.
- Under App Service Plan, select Create new App Service Plan. Type
moduleServerAppServicePlan
for the name and choose a Pricing plan. - Select the Next: Docker > button at the bottom of the page.
- In the Docker tab, select Single Container under Options and Private Registry for the Image Source. Under Private registry options, set the following values:
- Server URL:
https://crintentarchitectprodzanorth.azurecr.io
- Username:
anonymous
- Password:
1Ww/o4nfLPIKdComVBukyVGlmtWVgYm7MgfVPwwnfO+ACRAX3G9B
- Image and tag:
intent-architect/module-server:latest
- Server URL:
- Select the Review + create button at the bottom of the page.
- After validation runs, select the Create button at the bottom of the page.
- After deployment is complete, select Go to resource.
Set environment variables for the Docker image
- In the left pane, click on Configuration.
- For each of the following press the + New application setting, capture the Name, Value fields, leave the Deployment slow setting checkbox unchecked and press the OK button:
- Microsoft SQL Server connection string:
- Name:
ConnectionStrings__DefaultConnection
- Value: (A valid SQL Server connection string)
- Name:
- API keys:
- Name:
ApiKeys
- Value: (Semi-colon separated list of randomly generated API keys)
- Name:
- Azure Application Insights connection string (optional):
- Name:
APPLICATIONINSIGHTS_CONNECTION_STRING
- Value: (A valid Azure Application Insights connection string)
- Name:
- Microsoft SQL Server connection string:
- Press the 💾 Save button at the top of the pane.
Configuring Intent Architect clients to be able to use the Module Server
Intent Architect clients can use other Module Servers by entering their address into the Address field when adding a repository.
The value to enter Address is "base" URL for the website. For example if you had set up a local instance the address would be http://localhost:33800/
, if you had deployed it to Azure then the address would be something like https://myorganizationnamemoduleserver.azurewebsites.net/
.
SQL Server schema migration script
The following SQL Server script can be used to idempotently make sure that the database schema is at the latest version:
IF OBJECT_ID(N'[ModuleServer].[__EFMigrationsHistory]') IS NULL
BEGIN
IF SCHEMA_ID(N'ModuleServer') IS NULL EXEC(N'CREATE SCHEMA [ModuleServer];');
CREATE TABLE [ModuleServer].[__EFMigrationsHistory] (
[MigrationId] nvarchar(150) NOT NULL,
[ProductVersion] nvarchar(32) NOT NULL,
CONSTRAINT [PK___EFMigrationsHistory] PRIMARY KEY ([MigrationId])
);
END;
GO
BEGIN TRANSACTION;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE TABLE [ApplicationTemplates] (
[Id] uniqueidentifier NOT NULL,
[Identifier] nvarchar(150) NOT NULL,
[MajorVersion] int NOT NULL,
[MinorVersion] int NOT NULL,
[PatchVersion] int NOT NULL,
[DisplayName] nvarchar(150) NOT NULL,
[ShortDescription] nvarchar(1000) NULL,
[FullDescription] nvarchar(max) NULL,
[Priority] int NOT NULL,
[Authors] nvarchar(150) NULL,
[IconType] int NULL,
[IconSource] nvarchar(max) NULL,
[Tags] nvarchar(1000) NULL,
[ProjectUrl] nvarchar(512) NULL,
[LastUpdated] datetime2 NOT NULL,
[IsListed] bit NOT NULL,
[CreatedBy] nvarchar(50) NULL,
[CreateDateTime] datetime2 NULL,
[UpdatedBy] nvarchar(50) NULL,
[UpdateDateTime] datetime2 NULL,
[SupportedClientVersions] nvarchar(64) NOT NULL,
[MinClientMajor] int NOT NULL,
[MinClientMinor] int NOT NULL,
[MinClientPatch] int NOT NULL,
[MinClientInclusive] bit NOT NULL,
[MaxClientMajor] int NOT NULL,
[MaxClientMinor] int NOT NULL,
[MaxClientPatch] int NOT NULL,
[MaxClientInclusive] bit NOT NULL,
[Defaults_Name] nvarchar(128) NOT NULL,
[Defaults_RelativeOutputLocation] nvarchar(128) NOT NULL,
[Defaults_PlaceInSameDirectory] bit NOT NULL,
[Defaults_SeparateIntentFiles] bit NOT NULL,
[Defaults_SetGitIgnoreEntries] bit NOT NULL,
CONSTRAINT [PK_ApplicationTemplates] PRIMARY KEY ([Id])
);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE TABLE [Modules] (
[Id] uniqueidentifier NOT NULL,
[Identifier] nvarchar(150) NOT NULL,
[Summary] nvarchar(1000) NOT NULL,
[Authors] nvarchar(150) NOT NULL,
[LatestStableVersion] nvarchar(20) NOT NULL,
[SupportedClientVersions] nvarchar(64) NULL,
[IconUrl] nvarchar(max) NULL,
[Tags] nvarchar(1000) NULL,
[CreatedBy] nvarchar(50) NULL,
[CreateDateTime] datetime2 NULL,
[UpdatedBy] nvarchar(50) NULL,
[UpdateDateTime] datetime2 NULL,
CONSTRAINT [PK_Modules] PRIMARY KEY ([Id])
);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE TABLE [ApplicationTemplateFile] (
[Id] uniqueidentifier NOT NULL,
[Data] varbinary(max) NOT NULL,
CONSTRAINT [PK_ApplicationTemplateFile] PRIMARY KEY ([Id]),
CONSTRAINT [FK_ApplicationTemplateFile_ApplicationTemplates_Id] FOREIGN KEY ([Id]) REFERENCES [ApplicationTemplates] ([Id]) ON DELETE CASCADE
);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE TABLE [ModuleVersion] (
[Id] uniqueidentifier NOT NULL,
[Description] nvarchar(max) NULL,
[Version] nvarchar(20) NOT NULL,
[PublishedDate] datetime2 NOT NULL,
[Authors] nvarchar(150) NOT NULL,
[ProjectUrl] nvarchar(1000) NULL,
[Tags] nvarchar(1000) NULL,
[SupportedClientVersions] nvarchar(64) NULL,
[ReleaseNotes] nvarchar(max) NULL,
[IsListed] bit NOT NULL,
[ModuleId] uniqueidentifier NOT NULL,
CONSTRAINT [PK_ModuleVersion] PRIMARY KEY ([Id]),
CONSTRAINT [FK_ModuleVersion_Modules_ModuleId] FOREIGN KEY ([ModuleId]) REFERENCES [Modules] ([Id]) ON DELETE CASCADE
);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE TABLE [ModuleDependency] (
[Id] uniqueidentifier NOT NULL,
[ModuleVersionId] uniqueidentifier NOT NULL,
[ModuleId] nvarchar(150) NOT NULL,
[VersionSpec] nvarchar(40) NOT NULL,
CONSTRAINT [PK_ModuleDependency] PRIMARY KEY ([Id]),
CONSTRAINT [FK_ModuleDependency_ModuleVersion_ModuleVersionId] FOREIGN KEY ([ModuleVersionId]) REFERENCES [ModuleVersion] ([Id]) ON DELETE CASCADE
);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE TABLE [ModuleFile] (
[Id] uniqueidentifier NOT NULL,
[Data] varbinary(max) NOT NULL,
CONSTRAINT [PK_ModuleFile] PRIMARY KEY ([Id]),
CONSTRAINT [FK_ModuleFile_ModuleVersion_Id] FOREIGN KEY ([Id]) REFERENCES [ModuleVersion] ([Id]) ON DELETE CASCADE
);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE TABLE [ModuleSpecFile] (
[Id] uniqueidentifier NOT NULL,
[Data] nvarchar(max) NOT NULL,
CONSTRAINT [PK_ModuleSpecFile] PRIMARY KEY ([Id]),
CONSTRAINT [FK_ModuleSpecFile_ModuleVersion_Id] FOREIGN KEY ([Id]) REFERENCES [ModuleVersion] ([Id]) ON DELETE CASCADE
);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE UNIQUE INDEX [IX_ApplicationTemplates_Identifier_MajorVersion_MinorVersion_PatchVersion] ON [ApplicationTemplates] ([Identifier], [MajorVersion], [MinorVersion], [PatchVersion]);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE INDEX [IX_ApplicationTemplates_MaxClientMajor_MaxClientMinor_MaxClientPatch_MaxClientInclusive] ON [ApplicationTemplates] ([MaxClientMajor], [MaxClientMinor], [MaxClientPatch], [MaxClientInclusive]);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE INDEX [IX_ApplicationTemplates_MinClientMajor_MinClientMinor_MinClientPatch_MinClientInclusive] ON [ApplicationTemplates] ([MinClientMajor], [MinClientMinor], [MinClientPatch], [MinClientInclusive]);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE INDEX [IX_ModuleDependency_ModuleVersionId] ON [ModuleDependency] ([ModuleVersionId]);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE UNIQUE INDEX [IX_Modules_Identifier] ON [Modules] ([Identifier]);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
CREATE INDEX [IX_ModuleVersion_ModuleId] ON [ModuleVersion] ([ModuleId]);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230814124652_Initial'
)
BEGIN
INSERT INTO [ModuleServer].[__EFMigrationsHistory] ([MigrationId], [ProductVersion])
VALUES (N'20230814124652_Initial', N'8.0.6');
END;
GO
COMMIT;
GO
BEGIN TRANSACTION;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230817095136_AddModuleVersionIndex'
)
BEGIN
CREATE INDEX [IX_ModuleVersions_IsListed_SupportedClientVersions] ON [ModuleVersion] ([IsListed], [SupportedClientVersions]) INCLUDE ([ModuleId]);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230817095136_AddModuleVersionIndex'
)
BEGIN
INSERT INTO [ModuleServer].[__EFMigrationsHistory] ([MigrationId], [ProductVersion])
VALUES (N'20230817095136_AddModuleVersionIndex', N'8.0.6');
END;
GO
COMMIT;
GO
BEGIN TRANSACTION;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230817110919_BreakOutIcons'
)
BEGIN
ALTER TABLE [Modules] ADD [IconExists] bit NULL;
DECLARE @defaultSchema AS sysname;
SET @defaultSchema = SCHEMA_NAME();
DECLARE @description AS sql_variant;
SET @description = N'Although this can be inferred by whether or not the association to ModuleIcon is null, by storing it here we don''t have to worry about lazy loading the entity (which is reduces performance) to check if its null or do some other EF query.';
EXEC sp_addextendedproperty 'MS_Description', @description, 'SCHEMA', @defaultSchema, 'TABLE', N'Modules', 'COLUMN', N'IconExists';
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230817110919_BreakOutIcons'
)
BEGIN
CREATE TABLE [ModuleIcons] (
[Id] uniqueidentifier NOT NULL,
[Url] nvarchar(max) NOT NULL,
CONSTRAINT [PK_ModuleIcons] PRIMARY KEY ([Id]),
CONSTRAINT [FK_ModuleIcons_Modules_Id] FOREIGN KEY ([Id]) REFERENCES [Modules] ([Id]) ON DELETE CASCADE
);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230817110919_BreakOutIcons'
)
BEGIN
EXECUTE('
INSERT INTO [dbo].[ModuleIcons] ([Id], [Url])
SELECT [Id], [IconUrl] FROM [Modules]
WHERE [IconUrl] IS NOT NULL AND [IconUrl] LIKE ''data:%''
UPDATE [dbo].[Modules]
SET
[IconUrl] = CASE WHEN [IconUrl] IS NOT NULL AND [IconUrl] LIKE ''data:%'' THEN NULL ELSE [IconUrl] END,
[IconExists] = CASE WHEN [IconUrl] IS NOT NULL AND [IconUrl] LIKE ''data:%'' THEN 1 ELSE 0 END
')
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230817110919_BreakOutIcons'
)
BEGIN
DECLARE @var0 sysname;
SELECT @var0 = [d].[name]
FROM [sys].[default_constraints] [d]
INNER JOIN [sys].[columns] [c] ON [d].[parent_column_id] = [c].[column_id] AND [d].[parent_object_id] = [c].[object_id]
WHERE ([d].[parent_object_id] = OBJECT_ID(N'[Modules]') AND [c].[name] = N'IconExists');
IF @var0 IS NOT NULL EXEC(N'ALTER TABLE [Modules] DROP CONSTRAINT [' + @var0 + '];');
ALTER TABLE [Modules] ALTER COLUMN [IconExists] bit NOT NULL;
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20230817110919_BreakOutIcons'
)
BEGIN
INSERT INTO [ModuleServer].[__EFMigrationsHistory] ([MigrationId], [ProductVersion])
VALUES (N'20230817110919_BreakOutIcons', N'8.0.6');
END;
GO
COMMIT;
GO
BEGIN TRANSACTION;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20240130161055_ApplicationTemplate_Version_IsPrerelease'
)
BEGIN
ALTER TABLE [ApplicationTemplates] ADD [IsPrerelease] bit NOT NULL DEFAULT CAST(0 AS bit);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20240130161055_ApplicationTemplate_Version_IsPrerelease'
)
BEGIN
ALTER TABLE [ApplicationTemplates] ADD [Version] nvarchar(20) NOT NULL DEFAULT N'';
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20240130161055_ApplicationTemplate_Version_IsPrerelease'
)
BEGIN
EXECUTE('
UPDATE [dbo].[ApplicationTemplates]
SET Version = CONVERT(varchar(10), MajorVersion) + ''.'' + CONVERT(varchar(10), MinorVersion) + ''.'' + CONVERT(varchar(10), PatchVersion)')
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20240130161055_ApplicationTemplate_Version_IsPrerelease'
)
BEGIN
INSERT INTO [ModuleServer].[__EFMigrationsHistory] ([MigrationId], [ProductVersion])
VALUES (N'20240130161055_ApplicationTemplate_Version_IsPrerelease', N'8.0.6');
END;
GO
COMMIT;
GO
BEGIN TRANSACTION;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20240131082207_UpdatedIndex_IX_ApplicationTemplates_Identifier_Version'
)
BEGIN
DROP INDEX [IX_ApplicationTemplates_Identifier_MajorVersion_MinorVersion_PatchVersion] ON [ApplicationTemplates];
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20240131082207_UpdatedIndex_IX_ApplicationTemplates_Identifier_Version'
)
BEGIN
CREATE UNIQUE INDEX [IX_ApplicationTemplates_Identifier_Version] ON [ApplicationTemplates] ([Identifier], [Version]);
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20240131082207_UpdatedIndex_IX_ApplicationTemplates_Identifier_Version'
)
BEGIN
INSERT INTO [ModuleServer].[__EFMigrationsHistory] ([MigrationId], [ProductVersion])
VALUES (N'20240131082207_UpdatedIndex_IX_ApplicationTemplates_Identifier_Version', N'8.0.6');
END;
GO
COMMIT;
GO
BEGIN TRANSACTION;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20240910134034_AddCreateFolderForSolution'
)
BEGIN
ALTER TABLE [ApplicationTemplates] ADD [Defaults_CreateFolderForSolution] bit NULL;
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20240910134034_AddCreateFolderForSolution'
)
BEGIN
EXECUTE('
UPDATE [dbo].[ApplicationTemplates]
SET Defaults_CreateFolderForSolution = 1')
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20240910134034_AddCreateFolderForSolution'
)
BEGIN
DECLARE @var1 sysname;
SELECT @var1 = [d].[name]
FROM [sys].[default_constraints] [d]
INNER JOIN [sys].[columns] [c] ON [d].[parent_column_id] = [c].[column_id] AND [d].[parent_object_id] = [c].[object_id]
WHERE ([d].[parent_object_id] = OBJECT_ID(N'[ApplicationTemplates]') AND [c].[name] = N'Defaults_CreateFolderForSolution');
IF @var1 IS NOT NULL EXEC(N'ALTER TABLE [ApplicationTemplates] DROP CONSTRAINT [' + @var1 + '];');
ALTER TABLE [ApplicationTemplates] ALTER COLUMN [Defaults_CreateFolderForSolution] bit NOT NULL;
END;
GO
IF NOT EXISTS (
SELECT * FROM [ModuleServer].[__EFMigrationsHistory]
WHERE [MigrationId] = N'20240910134034_AddCreateFolderForSolution'
)
BEGIN
INSERT INTO [ModuleServer].[__EFMigrationsHistory] ([MigrationId], [ProductVersion])
VALUES (N'20240910134034_AddCreateFolderForSolution', N'8.0.6');
END;
GO
COMMIT;
GO
